SSS DUPLEXER SERIES
(has been browse 195 times)
SSS DUPLEXER SERIES

Part Number Nominal Freq Passband
Frequency		 Passband
Insertion
Loss		 Crossover
Insertion
Loss		 VSWR Stop Band
Attenuation		 Power
Handling
TGF-A4211-001 DC-2GHz
2-4GHz		 DC-1.9GHz
2.1-4GHz		 1.0dB 5.5dB 2.0 50dB@ 2.3-4GHz
DC-1.7GHz		 15W
TGF-A4212-001 DC-3GHz
3-6GHz		 DC-2.85GHz
3.15-6GHz		 1.0dB 5.5dB 2.0 50dB@ 3.45-6GHz
DC-2.55GHz		 15W
TGF-A4212-002 DC-4GHz
4-8GHz		 DC-3.8GHz
4.2-8GHz		 1.0dB 5.5dB 2.0 50dB@ 4.6-8GHz
DC-3.4GHz		 15W
TGF-A4213-001 DC-5GHz
5-10GHz		 DC-4.75GHz
5.25-10GHz		 1.0dB 5.5dB 2.0 50dB@ 5.75-10GHz
DC-4.25GHz		 15W
TGF-A4213-002 DC-6GHz
6-12GHz		 DC-5.7GHz
6.3-12GHz		 1.0dB 5.5dB 2.0 50dB@ 6.9-12GHz
DC-5.1GHz		 15W
TGF-A4214-001 DC-7GHz
7-14GHz		 DC-6.65GHz
7.35-14GHz		 1.0dB 5.5dB 2.0 50dB@ 8.05-14GHz
DC-5.95GHz		 15W
TGF-A4214-002 DC-8GHz
8-16GHz		 DC-7.6GHz
8.4-16GHz		 1.0dB 5.5dB 2.0 50dB@ 9.2-16GHz
DC-6.8GHz		 15W
TGF-A4215-001 DC-9GHz
9-18GHz		 DC-8.55GHz
9.45-18GHz		 1.0dB 5.5dB 2.0 50dB@ 10.35-18GHz
DC-7.65GHz		 15W
TGF-A4215-002 DC-10GHz
10-18GHz		 DC-9.5GHz
10.5-18GHz		 1.0dB 5.5dB 2.0 50dB@ 11.5-18GHz
DC-8.5GHz		 15W
TGF-A4216-001 DC-11GHz
11-18GHz		 DC-10.45GHz
11.55-18GHz		 1.0dB 5.5dB 2.0 50dB@ 12.65-18GHz
DC-9.35GHz		 15W
TGF-A4216-002 DC-12GHz
12-18GHz		 DC-11.4GHz
12.6-18GHz		 1.0dB 5.5dB 2.0 50dB@ 13.8-18GHz
DC-10.2GHz		 15W
TGF-A4217-002 DC-14GHz
14-18GHz		 DC-13.3GHz
14.7-18GHz		 1.0dB 5.5dB 2.0 50dB@ 16.1-18GHz
DC-11.9GHz		 15W
