SSS TRIPLEXER SERIES
(has been browse 212 times)
SSS TRIPLEXER SERIES

Part Number Nominal Freq Passband
Frequency		 Passband
Insertion
Loss		 Crossover
Insertion
Loss		 VSWR Stop Band
Attenuation		 Power
Handling
TGF-A4311-001 DC-2GHz
2-6GHz
6-18GHz		 DC-1.9GHz
2.1-5.7GHz
6.3-18GHz		 2.0dB 5.5dB 2.0 50dB@ 2.3-18GHz
DC-1.7GHz
6.9-18GHz
DC-5.1GHz		 15W
TGF-A4312-001 DC-4GHz
4-6GHz
6-18GHz		 DC-3.8GHz
4.2-5.7GHz
6.3-18GHz		 2.0dB 5.5dB 2.0 50dB@ 4.6-18GHz
DC-3.4GHz
6.9-18GHz
DC-5.1GHz		 15W
TGF-A4312-002 DC-4GHz
4-8GHz
8-18GHz		 DC-3.8GHz
4.2-7.6GHz
8.4-18GHz		 2.0dB 5.5dB 2.0 50dB@ 4.6-18GHz
DC-3.4GHz
9.2-18GHz
DC-6.8GHz		 15W
TGF-A4314-001 DC-8GHz
8-12GHz
12-18GHz		 DC-7.6GHz
8.4-11.4GHz
12.6-18GHz		 2.0dB 5.5dB 2.0 50dB@ 9.2-18GHz
DC-6.8GHz
13.8-18GHz
DC-10.2GHz		 15W
TGF-A4315-001 DC-10GHz
10-14GHz
14-18GHz		 DC-9.5GHz
10.5-13.3GHz
14.7-18GHz		 2.0dB 5.5dB 2.0 50dB@ 11.5-18GHz
DC-8.5GHz
16.1-18GHz
DC-11.9GHz		 15W
