| Part Number |
Frequency
Range |
Insertion
Loss |
Rrturn
Loss |
Channel
Isolation |
Power
Handling |
| TGF-C2218-001 |
8.28-8.328GHz
8.406-8.454GHz |
1.6dB |
20dB |
65dB |
100W |
| TGF-C2218-002 |
7.215-7.276GHz
7.412-7.437GHz |
1.7dB |
20dB |
70dB |
100W |
| TGF-C2221-001 |
10.157-10.29GHz
10.507-10.64GHz |
1.5dB |
20dB |
70dB |
100W |
| TGF-C2223-001 |
12.864-12.974GHz
13.13-13.24GHz
|
1.2dB |
17dB |
65dB |
100W |
| TGF-C2229-001 |
18.15-18.69GHz
19.16-19.69GHz
|
1.0dB |
16dB |
55dB |
100W |
| TGF-C2229-002 |
22.001-22.589GHz
23.009-23.597GHz
|
1.5dB |
18dB |
60dB |
100W |
| TGF-C2229-003 |
24.95-25.49GHz
25.96-26.5GHz
|
1.5dB |
18dB |
45dB |
100W |
| TGF-C2229-004 |
25.43-25.63GHz
26.3-26.5GHz
|
1.5dB |
15dB |
55dB |
100W |
| TGF-C2229-005 |
27.711-27.924GHz
28.137-28.35GHz
|
1.5dB |
21dB |
50dB |
100W |
| TGF-C2229-006 |
38.6-38.95GHz
39.3-39.65GHz
|
2.3dB |
16dB |
55dB |
100W |
| TGF-C2228-001 |
17.7-18.14GHz
19.26-19.7GHz
|
1.25dB |
18dB |
50dB |
100W |
| TGF-C2216-001 |
5.9825-6.0075GHz
6.2225-6.2475GHz
|
1.0dB |
22dB |
70dB |
100W |
| TGF-C2221-002 |
10.94-11.19GHz
11.43-11.72GHz
|
0.75dB |
20dB |
65dB |
100W |
