TGD-D SERIES DIRECTIONAL COUPLER FOR COMMUNICATION
(7/16 TYPE CONNECTOR)

Part Number	Freq.Range	Coupling	Insertion Loss	VSWR	Frequency Sensitivity	Directivity	Power Handling	PIM3
TGD-D1021-05	0.8-2.5GHz	5±0.5dB	0.4dB	1.25	± 0.7dB	20dB	50/200W	-150dBc
TGD-D1021-06	0.8-2.5GHz	6±0.5dB	0.4dB	1.25	± 0.7dB	20dB	50/200W	-150dBc
TGD-D1021-07	0.8-2.5GHz	7±0.5dB	0.4dB	1.25	± 0.7dB	20dB	75/200W	-150dBc
TGD-D1021-10	0.8-2.5GHz	10±0.8dB	0.4dB	1.25	± 0.7dB	20dB	100/200W	-150dBc
TGD-D1021-15	0.8-2.5GHz	15±1.0dB	0.3dB	1.25	± 0.7dB	20dB	200W	-150dBc
TGD-D1021-20	0.8-2.5GHz	20±1.0dB	0.3dB	1.25	± 0.7dB	20dB	200W	-150dBc
TGD-D1021-30	0.8-2.5GHz	30±1.0dB	0.3dB	1.25	± 0.7dB	20dB	200W	-150dBc
