product list->Filters
BAND PASS CAVITY FILTER SERIES
(has been browse 282 times)
BAND PASS CAVITY FILTER SERIES
Part Number
Frequency
Range
Insertion
Loss
VSWR
Stop Band
Stop Band Rejection
Power
Handling
TGF-B2120-002
8-12GHz
1.0dB
2.0
DC-7.4GHz
12.6-18GHz
35dB
30W
TGF-B2113-008
2.2-2.8GHz
1.0dB
1.5
DC-1.7GHz
3.3-6GHz
40dB
30W
TGF-B2122-002
10.96-12.84GHz
1.0dB
1.5
DC-10GHz
13.8-18GHz
55dB
30W
TGF-B2113-007
2.4-2.7GHz
1.0dB
1.3
DC-2.2GHz
2.9-6GHz
60dB
30W
TGF-B2118-002
7.5-8.5GHz
1.0dB
1.4
DC-7GHz
9-18GHz
55dB
30W
TGF-B2118-003
7.6-8.4GHz
1.0dB
1.4
DC-7GHz
9-18GHz
70dB
30W
TGF-B2124-002
12.9-14GHz
2.0dB
1.3
14.3-18GHz
30dB
30W
TGF-B2115-001
4-5GHz
1.0dB
1.4
DC-3.5GHz
5.5-8GHz
40dB
30W
TGF-B2122-003
10-12GHz
1.0dB
1.4
DC-9.5GHz
12.5-18GHz
50dB
30W
