COAXIAL LOW PASS FILTER SERIES
(has been browse 214 times)
COAXIAL LOW PASS FILTER SERIES

Part Number Frequency
Range		 Insertion
Loss		 VSWR Stop Band Stop Band Rejection Power
Handling
TGF-B3111-001 DC-1GHz 0.4dB 1.25 2-4GHz 60dB 60W
TGF-B3112-001 DC-2GHz 0.4dB 1.25 4-8GHz 60dB 60W
TGF-B3113-001 DC-3GHz 0.4dB 1.25 6-12GHz 60dB 60W
TGF-B3114-001 DC-4GHz 0.4dB 1.25 8-15GHz 60dB 60W
TGF-B3115-001 DC-5GHz 0.4dB 1.25 10GHz 60dB 60W
TGF-B3116-001 DC-6GHz 0.4dB 1.25 12GHz 60dB 60W
TGF-B3117-001 DC-7GHz 0.4dB 1.25 14GHz 60dB 60W
TGF-B3118-001 DC-8GHz 0.4dB 1.25 16GHz 60dB 60W
TGF-B3119-001 DC-9GHz 0.4dB 1.25 18GHz 60dB 60W
TGF-B3120-001 DC-10GHz 0.4dB 1.25 20GHz 60dB 60W
TGF-B3121-001 DC-11GHz 0.4dB 1.25 22GHz 60dB 60W
TGF-B3122-001 DC-12GHz 0.4dB 1.25 24GHz 60dB 60W
TGF-B3118-002 DC-8.5GHz 0.2dB 1.20 17-25GHz 45dB 60W
