product list->Filters
SSS BAND PASS FILTER SERIES
(has been browse 273 times)
SSS BAND PASS FILTER SERIES
Part Number
Frequency
Range
Insertion
Loss
VSWR
Stop Band
Stop Band Rejection
Power
Handling
TGF-A3113-001
2-4GHz
1.0dB
2.0
DC-1.6GHz
4.6-10GHz
50dB
15W
TGF-A3114-001
2-6GHz
1.0dB
2.0
DC-1.6GHz
6.9-14GHz
50dB
15W
TGF-A3115-001
2-8GHz
1.0dB
2.0
DC-1.6GHz
9.2-16GHz
50dB
15W
TGF-A3116-001
4-8GHz
1.0dB
2.0
DC-3.4GHz
9.2-16GHz
50dB
15W
TGF-A3119-001
6-12GHz
1.0dB
2.0
DC-5.1GHz
13.8-18GHz
50dB
15W
