product list->Filters
SSS LOW PASS FILTER SERIES
(has been browse 188 times)
SSS LOW PASS FILTER SERIES
Part Number
Frequency
Range
Insertion
Loss
VSWR
Stop Band
Stop Band Rejection
Power
Handling
TGF-A1111-001
DC-1GHz
1.0dB
1.8
1.2-3GHz
50dB
15W
TGF-A1112-001
DC-2GHz
1.0dB
1.8
2.3-6GHz
50dB
15W
TGF-A1113-001
DC-3GHz
1.0dB
1.8
3.45-8GHz
50dB
15W
TGF-A1114-001
DC-4GHz
1.0dB
1.8
4.6-10GHz
50dB
15W
TGF-A1115-001
DC-5GHz
1.0dB
1.8
5.75-12GHz
50dB
15W
TGF-A1116-001
DC-6GHz
1.0dB
1.8
6.9-14GHz
50dB
15W
TGF-A1117-001
DC-7GHz
1.0dB
1.8
8.05-15GHz
50dB
15W
TGF-A1118-001
DC-8GHz
1.0dB
1.8
9.2-16GHz
50dB
15W
TGF-A1119-001
DC-9GHz
1.0dB
1.8
10.35-16GHz
50dB
15W
TGF-A1120-001
DC-10GHz
1.0dB
1.8
11.5-17GHz
50dB
15W
TGF-A1121-001
DC-11GHz
1.0dB
1.8
12.65-17GHz
50dB
15W
TGF-A1122-001
DC-12GHz
1.0dB
1.8
13.8-18GHz
50dB
15W
TGF-A1123-001
DC-13GHz
1.0dB
2.0
14.95-18GHz
50dB
15W
TGF-A1124-001
DC-14GHz
1.0dB
2.0
16.1-19GHz
50dB
15W
