TGP-B SERIES POWER DIVIDER FOR COMMUNICATION (N TYPE CONNECTOR)
(has been browse 362 times)
TGP-B SERIES POWER DIVIDER FOR COMMUNICATION
(N TYPE CONNECTOR)

Part Number Description Freq.Range Insertion
Loss		 Isolation Input
VSWR		 Output
VSWR		 Amplitude
Balance
TGP-B0221 2-way 0.8-2.5GHz 0.40dB 20dB 1.25 1.20 ±0.30dB
TGP-B0321 3-way 0.8-2.5GHz 0.60dB 20dB 1.30 1.25 ±0.35dB
TGP-B0421 4-way 0.8-2.5GHz 0.70dB 20dB 1.30 1.25 ±0.30dB
