TGP-D SERIES HIGH POWER POWER DIVIDER FOR COMMUNICATION(7/16 TYPE CONNECTOR)
(has been browse 234 times)

TGP-D SERIES HIGH POWER POWER DIVIDER FOR COMMUNICATION
(7/16 TYPE CONNECTOR)

Part Number
Description
Freq.Range
Insertion
Loss
Input
VSWR
Forward Power
Handling(Avg/Peak)
 PIM3
TGP-D0221
2-way
0.8-2.5GHz
0.20dB
1.30
 300/3KW -150dBc
TGP-D0321
3-way
0.8-2.5GHz
0.30dB
 1.30 300/3KW -150dBc
TGP-D0421
4-way
0.8-2.5GHz
0.30dB
 1.30 300/3KW -150dBc
