product list->3 dB Hybrids
TGD-A3 SERIES 180°HYBRID AND COMBINER
(has been browse 102 times)
TGD-A3 SERIES
180° HYBRID AND COMBINER
Part Number
Freq.Range
Insertion
Loss
Isolation
VSWR
Amplitude
Balance
Phase
Balance
TGD-A3012
2-18GHz
2.50dB
14dB
1.80
±1.2dB
±14°
TGD-A3024
4-18GHz
2.00dB
15dB
1.80
±1.0dB
±12°
TGD-A3031
1-2GHz
0.60dB
22dB
1.40
±0.5dB
±10°
TGD-A3032
2-4GHz
0.60dB
20dB
1.60
±0.5dB
±10°
TGD-A3052
0.75-1.5GHz
0.60dB
22dB
1.40
±0.5dB
±10°
