TGD-B SERIES DIRECTIONAL COUPLER FOR COMMUNICATION (N TYPE CONNECTOR)
(has been browse 308 times)
TGD-B SERIES DIRECTIONAL COUPLER FOR COMMUNICATION
(N TYPE CONNECTOR)
Part Number
Freq.Range
Coupling
Insertion
Loss
VSWR
Frequency
Sensitivity
Directivity
TGD-B1200-10
0.5-2.0GHz
10±0.8dB
0.5dB
1.25
± 0.7dB
20dB
TGD-B1200-20
0.5-2.0GHz
20±1.0dB
0.4dB
1.25
± 0.7dB
20dB
TGD-B1200-30
0.5-2.0GHz
30±1.0dB
0.4dB
1.25
± 0.7dB
20dB
TGD-B1021-05
0.8-2.5GHz
5±0.5dB
0.5dB
1.25
± 0.7dB
20dB
TGD-B1021-06
0.8-2.5GHz
6±0.5dB
0.5dB
1.25
± 0.7dB
20dB
TGD-B1021-07
0.8-2.5GHz
7±0.5dB
0.5dB
1.25
± 0.7dB
20dB
TGD-B1021-10
0.8-2.5GHz
10±0.8dB
0.5dB
1.25
± 0.7dB
20dB
TGD-B1021-15
0.8-2.5GHz
15±1.0dB
0.5dB
1.25
± 0.7dB
20dB
TGD-B1021-20
0.8-2.5GHz
20±1.0dB
0.4dB
1.25
± 0.7dB
20dB
TGD-B1021-30
0.8-2.5GHz
30±1.0dB
0.4dB
1.25
± 0.7dB
20dB
TGD-B1022-05
0.8-4.0GHz
5±0.5dB
0.5dB
1.30
± 0.7dB
20dB
TGD-B1022-06
0.8-4.0GHz
6±0.5dB
0.5dB
1.30
± 0.7dB
20dB
TGD-B1022-07
0.8-4.0GHz
7±0.5dB
0.5dB
1.30
± 0.7dB
20dB
TGD-B1022-10
0.8-4.0GHz
10±1.0dB
0.5dB
1.30
± 0.7dB
20dB
TGD-B1022-15
0.8-4.0GHz
15±1.0dB
0.5dB
1.30
± 0.7dB
20dB
TGD-B1022-20
0.8-4.0GHz
20±1.0dB
0.5dB
1.30
± 0.7dB
18dB
TGD-B1022-30
0.8-4.0GHz
30±1.0dB
0.5dB
1.30
± 0.7dB
18dB
TGD-B1203-10
2.0-8.0GHz
10±1.0dB
0.6dB
1.30
± 0.7dB
20dB
TGD-B1203-20
2.0-8.0GHz
20±1.0dB
0.6dB
1.30
± 0.7dB
18dB
TGD-B1203-30
2.0-8.0GHz
30±1.0dB
0.6dB
1.30
± 0.7dB
18dB
