TGP-A SERIES WIDEBAND POWER DIVIDER
(has been browse 632 times)
ULTRA BROADBAND POWER DIVIDER SERIES

Part Number Description Freq.Range Insertion
Loss		 Isolation Input
VSWR		 Output
VSWR		 Amplitude
Balance		 Phase
Balance
TGP-A0211 2-way 1-18GHz 1.60dB 16dB 1.60 1.60 ±0.50dB ±10°
TGP-A0411 4-way 1-18GHz 2.90dB 14dB 1.80 1.60 ±0.80dB ±10°
TGP-A0212 2-way 2-18GHz 1.20dB 16dB 1.50 1.50 ±0.30dB ±5°
TGP-A0412 4-way 2-18GHz 2.20dB 16dB 1.65 1.60 ±0.60dB ±10°
TGP-A0812 8-way 2-18GHz
3.50dB 15dB 1.85 1.60 ±0.80dB ±10°
TGP-A0213 2-way 1-12.4GHz 1.50dB 16dB 1.45 1.35 ±0.40dB ±6°
TGP-A0413 4-way 1-12.4GHz 2.80dB 16dB 1.60 1.35 ±0.50dB ±7°
TGP-A0214 2-way 0.5-6GHz 0.80dB 18dB 1.40 1.30 ±0.20dB ±3°
TGP-A0414 4-way 0.5-6GHz 1.80dB 16dB 1.60 1.50 ±0.30dB ±4°
TGP-A0814 8-way 0.5-6GHz 2.80dB 16dB 1.60 1.50 ±0.30dB ±8°
TGP-A0215 2-way 1-8GHz 1.20dB 16dB 1.40 1.35 ±0.30dB ±6°
TGP-A0415 4-way 1-8GHz 2.20dB 15dB 1.50 1.40 ±0.40dB ±8°

4OCTAVE BANDWIDTH POWER DIVIDER SERIES

Part Number
Description
Freq.Range
Insertion
Loss
Isolation
Input
VSWR
Output
VSWR
Amplitude
Balance
Phase
Balance
2-way
0.5-2.0GHz
0.50dB
20dB
1.25
1.20
±0.20dB
±2°
4-way
0.5-2.0GHz
1.00dB
20dB
1.30
1.20
±0.30dB
±3°
8-way
0.5-2.0GHz
1.50dB
20dB
1.40
1.30
±0.40dB
±4°
2-way
0.8-2.5GHz
0.40dB
20dB
1.30
1.20
±0.20dB
±2°
4-way
0.8-2.5GHz
0.70dB
20dB
1.30
1.20
±0.30dB
±6°
8-way
0.8-2.5GHz
1.20dB
20dB
1.40
1.25
±0.50dB
±8°
16-way
0.8-2.5GHz
1.70dB
18dB
1.50
1.30
±0.40dB
±8°
2-way
1.0-4.0GHz
0.50dB
20dB
1.30
1.25
±0.30dB
±2°
4-way
1.0-4.0GHz
0.80dB
20dB
1.30
1.20
±0.30dB
±4°
8-way
1.0-4.0GHz
1.50dB
20dB
1.40
1.30
±0.40dB
±4°
2-way
2.0-8.0GHz
0.60dB
20dB
1.30
1.20
±0.30dB
±4°
3-way
2.0-8.0GHz
1.30dB
18dB
1.40
1.30
±0.80dB
-
4-way
2.0-8.0GHz
1.20dB
17dB
1.40
1.35
±0.40dB
±5°
6-way
2.0-8.0GHz
1.60dB
17dB
1.40
1.30
±1.00dB
±8°
8-way
2.0-8.0GHz
1.80dB
17dB
1.65
1.35
±0.70dB
±7°
12-way
2.0-8.0GHz
2.20dB
16dB
1.60
1.40
±1.00dB
±7°
2-way
4.0-18.0GHz
0.80dB
18dB
1.50
1.50
±0.40dB
±5°
4-way
4.0-18.0GHz
1.60dB
17dB
1.60
1.50
±0.50dB
±8°
8-way
4.0-18.0GHz
2.50dB
15dB
1.80
1.50
±0.60dB
±10°

OCTAVE BANDWIDTH POWER DIVIDER SERIES
Part Number Description Freq.Range Insertion
Loss		 Isolation Input
VSWR		 Output
VSWR		 Amplitude
Balance		 Phase
Balance
TGP-A0230 2-way 0.5-1GHz 0.35dB 20dB 1.20 1.15 ±0.20dB ±2°
TGP-A0430 4-way 0.5-1GHz 0.60dB 20dB 1.25 1.20 ±0.30dB ±3°
TGP-A0231 2-way 1-2GHz 0.35dB 20dB 1.20 1.15 ±0.20dB ±2°
TGP-A0431 4-way 1-2GHz 0.60dB 20dB 1.30 1.20 ±0.30dB ±3°
TGP-A0831 8-way 1-2GHz 1.00dB 20dB 1.30 1.20 ±0.40dB ±5°
TGP-A0232 2-way 2-4GHz 0.35dB 20dB 1.25 1.20 ±0.20dB ±2°
TGP-A0332 3-way 2-4GHz 0.60dB 18dB 1.30 1.30 ±0.30dB -
TGP-A0432 4-way 2-4GHz 0.60dB 20dB 1.30 1.20 ±0.30dB ±3°
TGP-A0832 8-way 2-4GHz 0.90dB 20dB 1.30 1.20 ±0.40dB ±5°
TGP-A0233 2-way 4-8GHz 0.50dB 20dB 1.25 1.20 ±0.30dB ±3°
TGP-A0433 4-way 4-8GHz 0.80dB 20dB 1.30 1.25 ±0.30dB ±3°
TGP-A0833 8-way 4-8GHz 1.20dB 18dB 1.50 1.25 ±0.40dB ±4°
TGP-A0234 2-way 6-18GHz 0.70dB 18dB 1.50 1.50 ±0.40dB ±5°
TGP-A0334 3-way 8-18GHz 1.20dB 18dB 1.60 1.50 ±0.60dB -
TGP-A0434 4-way 6-18GHz 1.30dB 18dB 1.60 1.50 ±0.50dB ±8°
TGP-A0834 8-way 6-18GHz 2.10dB 17dB 1.80 1.50 ±0.80dB ±10°
TGP-A1234 12-way 8-18GHz 2.50dB 14dB 1.80 1.50 ±1.00dB ±10°
